Delta Electronics AC Motor Drive VFD-G User Manual
Page 22
Chapter 1 Introduction|
Revision July 2008, EG03, SW V1.06
1-13
H2
H
H1
W
W1
D
R F
Unit: mm [inch]
Frame
W
W1
H
H1
H2
D
F
G
425.0[16.73] 381.0[15.00]
850.0[33.46]
819.5[32.26] 764.0[30.08]
264.0[10.39]
6.5[0.26]
NOTE
Frame G: VFD1100F43C-G, VFD1320F43A-G, VFD1600F43A-G
Unit: mm [inch]
Frame
W
W1
H
H1
H2
D1
F
H
547.0[21.54] 480.0[18.90] 1150.0[45.28] 1119.0[44.06] 1357.6[53.45] 360.0[14.17]
13.0[0.51]
NOTE
Frame H: VFD1850F43A-G, VFD2200F43A-G
