Appendix B Accessories|
B-6 Revision July 2008, EG03, SW V1.06
B.4 AC Reactor
B.4.1 AC Input Reactor Recommended Value
460V, 50/60Hz, 3-Phase
Inductance (mh)
kW HP
Fundamental
Amps
Max. continuous
Amps
3% impedance 5% impedance
5.5 7.5 12 18 2.5 4.2
7.5 10 18 27 1.5 2.5
11 15 25 37.5 1.2 2
15 20 35 52.5 0.8 1.2
18.5 25 35 52.5 0.8 1.2
22 30 45 67.5 0.7 1.2
30 40 55 82.5 0.5 0.85
37 50 80 120 0.4 0.7
45 60 80 120 0.4 0.7
55 75 100 150 0.3 0.45
75 100 130 195 0.2 0.3
90 125 160 240 0.15 0.23
110 150 200 300 0.11 0.185
132 175 250 375 0.09 0.15
160 215 320 480 0.075 0.125
185 250 400 560 0.06 0.105
220 300 500 700 0.05 0.085
460V DC Choke
Input Voltage kW HP DC Amps Inductance (mh)
5.5 7.5 18 3.75
7.5 10 25 4.00
11 15 32 2.68
15 20 50 2.00
18.5kW~132kW(25HP~175HP): Built-in DC Reactor
160kW~220kW(215HP~300HP): Built-in AC Reactor
