Chapter 4 Parameters|
Revision July 2008, EG03, SW V1.06 4-37
Group 3: Output Function Parameters
03 - 00 Multi-function Output terminal 1 (Relay)
Settings 00-21 Factory Setting: 01
Setting Functions Descriptions
00 Disabled
01 Indication during
operation
The corresponding output will be closed during operation
(including DC braking time).
02 Master frequency
attained
The corresponding output will be closed when output
frequency reaches master frequency command.
03 Zero Speed (including
shutdown) The corresponding output will be closed when the AC drive
has no output voltage signal.
04 Over-torque The corresponding output relay will be closed when the AC
drives output current exceeds the over-torque detection
level 06-04.
05 External Fault The corresponding output will be closed when the EF is
enabled. (Pr. 04-00 to 04-03)
06 Low voltage detection The corresponding output will be closed when the DC Bus
voltage drops below our threshold. The keypad will display
“Lu”.
07 Operation Mode
indication
The corresponding output will be closed when the AC
drives “Operation Command” is controlled by the external
terminals.
08 Fault Indication The corresponding output will be closed when AC drive
has experienced a fault.
09 Master Frequency
Attained 1
The corresponding output will be closed when the AC
drives output frequency exceeds (Pr.03-08) Master
Frequency Attained 1.
10 Master Frequency
Attained 2
The corresponding output will be closed when the AC
drives output frequency exceeds (Pr.03-09) Master
Frequency Attained 2.
11 Over Temperature
indication
The corresponding output will be closed when the AC drive
temperature exceeds its rating.
12 Drive Ready The corresponding output will be closed the when the AC
drive is ready and has no faults.
13 External Emergency Stop
(EF1) The corresponding output will be closed when multi-
function input terminals (Pr.04-00 to 04-03) are set to
emergency stop and then activated.
14 Software braking output The corresponding output will be closed when the AC
drives DC bus voltage exceeds (Pr.08-19) the braking
level.
15 OL or OL1 overload
warning The corresponding output will be closed upon an overload
(OL or OL1) fault.
16 Low current indication The corresponding output will be closed when the AC
drives output current is lower than the Low Current setting
(Pr.06-08).
