Revision July 2008, EG03, SW V1.06

A-1

Appendix A Specifications

Voltage Class

460V Class

Model Number VFD-



G43X 055 075 110 150 185 220 300 370 450 550 750 900 1100 1320 1600 1850 2200

Max. Applicable Motor Output
(kW)

5.5 7.5

11

15 18.5 22

30

37

45 55 75

90

110

132 160 185 220

Max. Applicable Motor Output
(HP)

7.5 10

15

20

25

30

40

50

60 75 100 125 150

175 215 250 300

Rated Output Capacity (KVA) 10 14

18

25

29

34

46

56

69 84 114 137 168

198 236 281 350

Rated Output Current (A)

13 18

24

32

38

45

60

73

91 110 150 180 220

260 310 370 460

Maximum Output Voltage (V)

Proportional to Input Voltage

Rated Frequency (Hz)

0.10-120.00Hz

Ou

tp

ut

R

ati

ng

Carrier Frequency (kHz)

4-6

3-6

2-6

2-4

Rated Input Current (A)

14 19

25

32

39

49

60

73

91 120 160 160 200

240 300 380 400

Rated Voltage

3-phase 342-528 V

Input Rat

ing

Frequency Tolerance

47 – 63 Hz

General Specifications

Model Number VFD-



G43X 055 075 110 150 185 220 300 370 450 550 750 900 1100 1320 1600 1850 2200

Control System

SPWM (Sinusoidal Pulse Width Modulation, carrier frequency 2-6kHz)

Output Frequency
Resolution

0.01Hz

Torque Characteristics

Including the auto-torque, auto-slip compensation; starting torque can be 150% at
1.0Hz

Overload Endurance

150% of rated current for 1 minute
(F>15Hz)

120% of rated current
for 1 minute

Accel/Decel Time

1-36000/0.1-3600.0/0.01-360.00 seconds (3 Independent settings for Accel/Decel
Time)

V/F Pattern

Adjustable V/F pattern

C

ontr

o

l C

h

ar

acter

isti

cs

Stall Prevention Level

20 to 150%, Setting of Rated Current

Keypad

Setting by

Frequency
Setting

External
Signal

2 sets of analog inputs, 15 Multi-Function Inputs, RS-485 interface (MODBUS),
External terminals UP/DOWN Key

Keypad

Set by RUN, STOP and JOG

Operation
Setting
Signal

External
Signal

Operation by FWD, REV, JOG and communication operation

Multi-Function Input
Signal

Multi-step selection 0 to 15, Jog, accel/decel inhibit, first to forth accel/decel switches,
counter, external Base Block (NC, NO), JOG

Multi-Function Output
Indication

AC Drive Operating, Frequency Attained, Desired Frequency Attained, Zero speed,
Base Block, Fault Indication and Local/Remote indication

Oper

ati

ng C

har

acter

ist

ics

Analog Output Signal

2 sets of Analog frequency/current signal output
