Chapter 4 Parameters|
Revision July 2008, EG03, SW V1.06 4-7
Group 3 Output Function Parameters
Parameter Functions Settings
Factory
Setting
Customer
03-00 Multi-function Output
Terminal 1
(Relay)
00: disabled
01: Indication during operation
02: Master frequency attained
03: Zero Speed (including shutdown)
04: Over-torque
05: External Fault
06: Low voltage detection
07: Operation Mode indication
08: Fault indication
09: Master Frequency Attained 1
10: Master Frequency Attained 2
11: Over Temperature indication
12: Drive Ready
13: External Emergency Stop (EF1)
14: Software Braking Output
15: OL or OL1 Overload Warning
16: Low Current Indication
17: PID Feedback Error Indication
18: PLC Program Running
19: PLC Program Step Completed
20: PLC Program Completed
21: PLC Operation Paused 01
03-01 Reserved
03-02 Master
Frequency
Attained 1
0.00~160.00 Hz 0.00
03-03 Master Frequency
Attained 2
0.00~160.00 Hz 0.00
03-04 DC Fan Control 00: Fan runs on power up.
01: Fan begins upon a RUN command. Fan
stops 1 minute after a STOP command.
02: Fan begins upon a RUN command. Fan
stops after a STOP command
03: Fan is controlled by temperature.
Fan will be started at approximate 60°C.
00
03-05 Analog Output Signal
1
00
03-06 Analog Output Signal
2
00: Output frequency
01: Output current
02: Output voltage
03: Frequency command
04: Power factor loading
01
03-07 Analog Output Gain 1 01~200% 100
03-08 Analog Output Gain 2 01~200% 100
03-09 Analog Output 2
Selection
00: 0~20mA
01: 4~20mA 01
