Chapter 3 Keypad and Start Up|
3-4 Revision July 2008, EG03, SW V1.06
3.2 Operation Method
The operation method can be set via communication, digital keypad and control terminals. Please
choose a suitable method depending on application and operation rule.
Operation Method Frequency Source Operation Command Source
Operate from the
communication
Refer to the communication address
2001H setting for details.
(Parameter setting: Pr.02-00=03) Refer to the communication address
2000H setting for details.
(Parameter setting: Pr.02-01=03/04)
U
F
H
STOP RUN REV
VFD-PU01
FWD JOG
JOG
RUN
RESET
STOP
VFD-PU01 keypad
RUN
RESET
STOP
F WD
EF
MI1
MI2
MI3
MI4
DCM
+24V
F WD/ST OP
Digital Si gnal Common
*Don't apply the mains voltage
dir ectly to abov e terminals.
E.F.
Multi-s tep1
Multi-s tep2
Multi-s tep3
Multi-s tep4
F ac tor y
default
Multi-function
input
terminals
REV
REV/STO P
Operate from
external signal
MI1-DCM (Set Pr.04-00=13)
MI2-DCM (Set Pr.04-01=14) FWD-DCM (Set to FWD/STOP)
REV-DCM (Set to REV/STOP)
