Delta Electronics AC Motor Drive VFD-G User Manual
Page 39
Chapter 2 Installation and Wiring|
2-16
Revision July 2008, EG03, SW V1.06
50 HP to 60 HP (VFD370F43A-G, VFD450F43A-G)
R/L1
+1
+2
-
S/L2 T/L3
U/T1 V/T2 2/T3
POWER
IM
MOTOR
3
POWER
ALARM
CHARGE
Control Terminal
Torque: 4Kgf-cm (3 in-lbf)
Wire: 12-24 AWG
Power Terminal
Torque: 57kgf-cm (49.5 in-lbf) min.
Wire: VFD370F43A-G: 3AWG
VFD450F43A-G: 2AWG
Wire Type: Stranded copper only, 75° C
