Chapter 4 Parameters|
4-24 Revision July 2008, EG03, SW V1.06
Code AC Drive Status Explanation
22 PHL (phase loss) Input power lacks phase.
3-phase input power is unbalance and exceeds
specification.
23 Lc (Low Current) Low current detection during operation.
24 FbL(Feedback Loss) Feedback signal is abnormal.
25 Reserved
26
FANP Fan Power Fault
27 FF1 Fan 1 Fault
28 FF2 Fan 2 Fault
29 FF3 Fan 3 Fault
30 FF123 Fan 1, 2, 3 Fault
31 FF12 Fan 1, 2 Fault
32 FF13 Fan 1, 3 Fault
33 FF23 Fan 2, 3 Fault
34 Fv Gate Drive Low Voltage Protect
35~40 Reserved
41 HPF1 GFF hardware error
42 HPF2 CC,OC hardware error
43 HPF3 OC hardware error
44 HPF4 OV hardware error
45 CF3.3 U-phase error
46 CF3.4 V-phase error
47 CF3.5 W-phase error
48 CF3.6 OV or LV
49 CF3.7 Isum error
50 CF3.8 Temperature sensor error
00 - 02 AC Drive Status Indication 2
Factory setting: Read Only
Display Bit 0~1: 00: Run LED is off and stop led is on. (AC Drive stopping)
01: Run LED is blink and stop led is on. (AC Drive deceleration to
stop)
10: Run LED is on and stop led is blink. (AC Drive standby)
11: Run LED is on and stop led is off. (AC Drive running)
Bit 2: 1: Jog on.
Bit 3~4: 00: Rev LED is off and FWD led is on. (Forward)
01: Rev LED is blink and FWD led is on. (Reverse to Forward)
10: Rev LED is on and FWD led is blink. (Forward to Reverse)
11: Rev LED is on and FWD led is off. (Reverse)
Bit 5-7: Reserved
