Chapter 4 Parameters|
4-16 Revision July 2008, EG03, SW V1.06
Parameter Functions Settings
Factory
Setting
Customer
09-05 Even/Odd Parity and
Stopping Parity Setting 00: None parity + 2 stop bit
01: Even parity + 2 stop bit
02: Odd parity + 2 stop bit
03: None parity + 1 stop bit
04: Even parity + 1 stop bit
05: Odd parity + 1 stop bit 00
09-06 Communication
Operation Command 1
Bit0~1: 00: Disable
01: Stop
10: Start-up
11: JOG start-up
Bit2~3: Reserved
Bit4~5: 00: No function
01: FWD command
10: REV command
11: Change direction command
Bit6~7: 00: 1st step accel/decel speed
01: 2nd step accel/decel speed
10: 3rd step accel/decel speed
11: 4th step accel/decel speed
Bit8~11:
0000: Master speed
0001: 1st step speed
0010: 2nd step speed
0011: 3rd step speed
0100: 4th step speed
0101: 5th step speed
0110: 6th step speed
0111: 7th step speed
1000: 8th step speed
1001: 9th step speed
1010: 10th step speed
1011: 11th step speed
1100: 12th step speed
1101: 13th step speed
1110: 14th step speed
1111: 15th step speed
Bit12: Select Bit6~11 function
Bit13~15 Reserved
00
09-07 Communication
Frequency Setting
0~160.00Hz 60.00
09-08 Communication
Operation Command 2
Bit0: 1: EF ON
Bit1: 1: Reset
Bit2: 0: BB OFF, 1: BB ON
Bit3~15: Reserved 00
