Revision July 2008, EG03, SW V1.06 B-1
Appendix B Accessories
B.1 All Brake Resistors & Brake Units Used in AC Motor Drives
Note: Please only use DELTA resistors and recommended values. Other resistors and values will void
Delta’s warranty. Please contact your nearest Delta representative for use of special resistors. For
instance, in 460 V series, 100 HP, AC drive has 2 brake units with total of 16 brake resistors, so each
brake unit uses 8 brake resistors. There should be at least 10 cm away from AC drive to avoid
possible noise. Refer to the “Brake Unit Module User Manual” for further detail.
Applicable
Motor
Voltage HP kW
Ì Full
Load
Torque
KG-M
Equivalent
Resistors
Specification
for Each AC
Drive
Brake Unit
Model VFDB
No. of Unit
Used
Brake
Resistors Model
No. of Units Used
Brake
Torque
10%ED%
Minimum
Equivalent
Resistor Value
for Each AC
Drive
7.5 5.5 3.111 500W 100Ω BR500W100 1 125 60Ω
10 7.5 4.148 1000W 75Ω BR1K0W075 1 125 45Ω
15 11 6.186 1000W 50Ω BR1K0W050 1 125 50Ω
20 15 8.248 1500W 40Ω BR1K5W040 1 125 40Ω
25 18.5 10.281 4800W 32Ω 4030 1 BR1K2W008 4 125 32Ω
30 22 12.338 4800W 27.2Ω 4030 1 BR1K2W6P8 4 125 27.2Ω
40 30 16.497 6000W 20Ω 4030 1 BR1K5W005 4 125 20Ω
50 37 20.6 9600W 16Ω 4045 1 BR1K2W008 8 125 16Ω
60 45 24.745 9600W 13.6Ω 4045 1 BR1K2W6P8 8 125 13.6Ω
75 55 31.11 12000W 10Ω 4030 2 BR1K5W005 8 125 10Ω
100 75 42.7 19200W 6.8Ω 4045 2 BR1K2W6P8 16 125 6.8Ω
120 90 52.5 13500W 5Ω 4132 1 BR1K5W005 9 120 5Ω
150 110 61 21600W 4Ω 4132 1 BR1K2W008 18 120 4Ω
175 132 73.5 21600W 4Ω 4132 1 BR1K2W008 18 100 4Ω
215 160 89 21600W 3.4Ω 4132 1 BR1K2W6P8 18 97 3.4Ω
250 185 103 27000W 2.5Ω 4132 2 BR1K5W005 18 115 2.5Ω
460V Se
ries
300 220 122.5 27000W 2.5Ω 4132 2 BR1K5W005 18 96 2.5Ω
