Delta Electronics AC Motor Drive VFD-G User Manual
Page 73
Chapter 4 Parameters|
4-22
Revision July 2008, EG03, SW V1.06
Output Signal for Base Block
Applications Purpose
Functions
Related
Parameters
General application
Provide a signal for
running status
When executing Base Block, a signal
is sent by an external system or
control wiring.
03-00
Overheat Warning for Heat Sink
Applications Purpose
Functions
Related
Parameters
General application
For safety
When heat sink is overheated, it will
send a signal by an external system or
control wiring.
03-00
Multi-function Analog Output
Applications Purpose
Functions
Related
Parameters
General application
Display running
status
The value of frequency, output
current/voltage can be read by
adding a frequency meter or
voltage/current meter.
03-05~03-09
