5-1 Specifications
5-3 IL-E
5
Specif
ications
*1 The classification is implemented based on IEC60825-1 following the requirement of Laser Notice
No.50 of FDA (CDRH).
*2 Value when measuring the KEYENCE standard target (white diffuse object).
*3 The F.S. of all of the models are as follows. IL-030: ±5 mm, IL-065: ±10 mm, IL-100: ±20 mm,
IL-300: ±140 mm, IL-600: ±400 mm, IL-2000: +1000 to -1500 mm
*4 Is the value for when our standard object (white diffuse object) is measured at an average of 128
times and with a sampling rate of 1 ms from a standard distance. (IL-300/IL-600 is 2 ms and IL-2000
is 5 ms)
*5 Value when the sampling rate is set to 2 ms or 5 ms.
Model IL-030 IL-065 IL-100 IL-300 IL-600 IL-2000
Mounting distance 30 mm 65 mm 100 mm 300 mm 600 mm 2000 mm
Measurement range
20 to 45
mm
55 to 105
mm
75 to 130
mm
160 to 450
mm
200 to
1000 mm
1000 to
3500 mm
Light source
Red semiconductor laser; wavelength 655 nm (visible light)
Laser Class
Class 1
(FDA
CDRH
Part
1040.10 *1 ,
IEC
60825-1)
Class 2 (FDA CDRH Part1040.10 *1 , IEC 60825-1)
Output 220 μW 560 μW
Spot diameter
(at the reference distance)
Approx.
200 x 750
μm
Approx.
550 x 1750
μm
Approx.
400 x 1350
μm
Approx.
ø500 μm
Approx.
ø1600 μm
Approx.
1400 x
7000 μm
Linearity *2 *3
±0.1% of
F.S.
(When
used
under
25 to 35
mm)
±0.1% of
F.S.
(When
used
under
55 to 75
mm)
±0.15% of
F.S.
(When
used
under
80 to 120
mm)
± 0.25% of
F.S.
(When
used
under
160 to 440
mm)
±0.25% of
F.S. (When
used
under 200
to
600 mm)
± 0.16% of
F.S.
(When
used
under
1000 to
3500 mm)
±0.5% of
F.S. (When
used
under 200
to 1000
mm)
Repeatability *4 1 μm 2 μm 4 μm 30 μm 50 μm 100 μm
Sampling rate 0.33/1/2/5 ms (Variable to 4 levels)
Operating indicators
Laser emission warning indicator: green LED,
Analog range indicator: orange LED,
Reference distance indicator: red/green LED
Temperature characteristic *3 0.05%
of F.S./°C
0.06%
of F.S./°C
0.06%
of F.S./°C
0.08%
of F.S./°C
0.08%
of F.S./°C
0.016%
of F.S./°C
Environmental
resistance
Enclosure rating IP67
Ambient light *5
Incandescent
lamp:
5000 lx
Incandescent lamp:
7500 lx
Incandescent lamp:
5000 lx
Incandescent
lamp:
10000 lx
Ambient
temperature
-10 to + 50°C (No condensation and freezing)
Relative humidity 35 to 85% RH (No condensation)
Vibration 10 to 55 Hz, 1.5 mm double amplitude, 2 hours each for X, Y, and Z axes
Pollution degree 3
Material
Housing material: PBT, Metal: SUS304, Packing: NBR,
Lens cover: Glass, Cable: PVC
Weight
Approx.
60 g
Approx. 75 g Approx. 135 g
Approx.
350 g
