CanogaOS Command Reference
29-12
vpls2 720 0 0 0 Inactive
vpls1 7000 1 0 0 Active
In the following example, the show mpls vpls detail command is used to
display detailed VPLS information:
Switch# show mpls vpls detail
Virtual Private LAN Service Instance: vpls2, ID: 720
Group ID: 0, Configured MTU: NULL
Description: none
AC interface :
Name TYPE Vlan
eth-0-6 Ethernet ALL
Virtual Private LAN Service Instance: vpls1, ID: 7000
Group ID: 0, Configured MTU: NULL
Description: none
AC interface :
Name TYPE Vlan
eth-0-5 Ethernet ALL
Mesh Peers :
Peer PW Type State
202.198.25.2 RAW UP
In the following example, the show mpls vpls mesh command is used to
display MPLS VPLS Mesh Forwarding information:
Switch# show mpls vpls mesh
VPLS-ID Peer Addr In-Label Out-Intf Out-Label Type Lkps/St
7000 202.198.25.2 1026 eth-0-9 1028 RAW 2/Up
Related Commands
