244 | Installing System Components
CAUTION: If removed, you must replace the power distribution board 2 at the
bottom and the power distribution board-connector before replacing the first
power distribution board at the top.
1 If removed, first place the power distribution board 2 in the system.
See Figure 3-65. Otherwise skip to step 5.
NOTE: To install the power distribution board 2 that is below the first power
distribution board, angle the board during installation.
2 Replace the screws securing the power distribution board 2 to the
system. See Figure 3-65.
3 Replace the power distribution board-connector. See Figure 3-64.
4 Connect all the cables to the power distribution board 2. See Figure 3-
67.
You must route these cables properly through the tabs on the chassis to
prevent them from being pinched or crimped.
5 Replace the first power distribution board to the system. See Figure 3-
63.
6 Replace the screws securing the first power distribution board to the
system. See Figure 3-63.
7 Connect all the cables to the first power distribution board. See Figure
3-66.
You must route these cables properly through the tabs on the chassis to
prevent them from being pinched or crimped.
8 Replace the power supply. See “Installing a Power Supply” on page 155.
9 Close the system. See “Closing the System” on page 234.
10 Reconnect the system to its electrical outlet and turn on the system,
including any attached peripherals.
