System Board
Removing a System Board
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
1 Remove the system-board assembly. See “Removing a System-Board
2 Remove the air baffle for 1U node. See “Removing the Air Baffle ” on
page 159.
3 Remove the expansion-card assembly. See “Removing the Expansion
4 Remove the heat sink. See “Removing the Heat Sink” on page 160.
5 Remove the memory modules. See “Removing the Memory Modules”
on page 225.
6 If installed, remove the SAS mezzanine card or 1GbE mezzanine card
or 10GbE mezzanine card. See “Removing the LSI 2008 SAS
Mezzanine Card” on page 208,”Removing the 1GbE Mezzanine Card”
on page 212 and “Removing the 10GbE Mezzanine Card” on page 217.
7 Disconnect all the cables from the system board.
8 Remove the eight screws and then slide the system board. See Figure 3-
CAUTION: Do not lift the system board by grasping a memory module, processor,
or other components.
9 Grasp the system board by the edges and lift the system board away
from the system-board assembly. See Figure 3-57.
