Page 217
Installing System Components | 217
the system-board assembly. See Figure 3-47.
5 Place the expansion-card bracket into the system-board assembly. See
Figure 3-46 for 1U node. See Figure 3-17 for 2U node.
6 Replace the screws that secure the expansion-card bracket.
7 Reconnect all the cables to the 1GbE mezzanine card.
8 Replace the system-board assembly. See "Installing a System-Board
Removing the 10GbE Mezzanine Card
NOTE: The 10GbE mezzanine card is seated in PCI-E Gen3 x8 mezzanine slot 3 on
the system board, which is not active in 1-processor configuration. See “System
Board Connectors” on page 309 for the location.
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
1 Remove the system-board assembly. See “Removing a System-Board
2 Disconnect all the cables from the 10GbE mezzanine card.
