166 | Installing System Components
Interposer Extender for 2U Node
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
NOTE: This section is applicable to systems with 2U node only.
Removing the Interposer Extender for 2U Node
1 Remove the system-board assembly. See “Removing a System-Board
Assembly" on page 157.
2 Disconnect all the cables from the interposer extender. See Figure 5-10.
