Installing System Components | 195
LSI 9265-8i RAID Battery
Removing the LSI 9265-8i raid battery Assembly
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not
covered by your warranty. Read and follow the safety instructions that came with
the product.
NOTE: The information in this section applies only to systems intalled with the LSI
9265-8i card.
1 Remove the system-board assembly. See “Removing a System-Board
Assembly" on page 157.
2 When removing the LSI 9265-8i RAID battery assembly for 1U node,
skip to step 5; for 2U node, continue the steps.
3 Remove the interposer extender. See “Removing the Interposer
Extender” on page 166.
4 Remove the interposer extender tray. See “Removing the Interposer
Extender Tray” on page 168.
5 Disconnect the cable connecting to the LSI 9265-8i card.
6 Remove the screws that secure the LSI9265-8i RAID battery assembly
to the system board. See Figure 3-31.
7 Lift the LSI 9265-8i RAID battery assembly away from the system
board. See Figure 3-31.
