Installing System Components | 149


Removing a 2.5-inch Hard-Drive Blank

CAUTION: To maintain proper system cooling, all empty hard-drive bays must
have drive blanks installed.

NOTE: This section is applicable to systems with hot-swappable hard drives only.

3 Pull the handle to remove the 2.5-inch hard-drive blank out of the

hard-drive bay. See Figure 3-4.

Figure 3-4. Removing or Installing a 2.5-inch Hard-Drive Blank

1

2.5-inch hard-drive blank

2

handle

3

latch

Installing a 2.5-inch Hard-Drive Blank

1 With the latch side facing up, slide the latch into the hard-drive bay

first.

2 Push the 2.5-inch hard-drive with a slight inclination into the hard-

drive bay until the hard-drive blank is seated in place. See Figure 3-4.
