20 | About Your System
Table 1-2. Hard-Drive Status Indicators−For 2.5” Hard-Drive Backplane for
Expander Configuration
Controller
Hard
Drive
Type Function
Activity LED Status LED
Green
Green Amber
LSI 9265
/LSI 2008
/LSI 9210 SAS
/SATA2 Slot Empty Off Off Off
Drive On-line Blinking
when active On Off
Drive Identify /
Preparing for
Removal Blinking
when active On
250 ms
Off
250 ms Off
Drive Rebuild Blinking
when active On
400 ms
Off
100 ms Off
Drive Failed Off Off On
150 ms
Off
150 ms
Predicted
Failure (SMART) Blinking
when active On
500 ms
Off
500 ms
Off
1000 ms Off
500 ms
On
500 ms
Off
1000 ms
Rebuild Abort Off On
3000 ms
Off
9000 ms Off
6000 ms
On
3000 ms
Off
000 ms
