Using the System Setup Program | 129
Token Setup option Description
4858 WHEA Support Enables Windows Hardware Error Architecture.
4859 NIC
Enumeration
Default, Set PXE boot from on-board NIC then Add-on
NIC adapter.
485A
NIC
Enumeration
Set PXE boot from Add-on NIC adapter then on-board
NIC.
485B PCI-E Generation Set the PCI signaling rate at Gen3 8.0 Gigabits
bandwidth.
485C PCI-E Generation Set the PCI signaling rate at Gen2 5.0 Gigabits
bandwidth.
485D PCI-E Generation Set the PCI signaling rate at Gen1 2.5 Gigabits
bandwidth.
NOTE: The PCI-E Gen2 x16 slot 1 and slot 2 are supported up to Gen2 5.0 Gigabits
bandwidth. If user inserts Gen3 .0 devices into the 2 slots that will only train at Gen 2.0
speed, not Gen 3.0.
485E Reboot on WOL
(ROW)
Disables the ROW in default, Reboot on WOL(ROW) is
a feature which repurposes the traditional Wake on LAN
(WOL) signal to reboot the motherboard. During system
is in S0/S3
state, when a WOL packet is received by the NIC, the
wake‐up signal generated by the NIC
shall cause a hardware reboot of the motherboard.
485F Reboot on WOL
(ROW) Enables the ROW, Reboot on WOL(ROW) is a feature
which repurposes the traditional Wake on LAN (WOL)
signal to reboot the motherboard. During system is in
S0/S3 state, when a WOL packet is received by the NIC,
the wake‐up signal generated by the NIC shall cause a
hardware reboot of the motherboard.
4860 USB PORT with
BMC This feature will allow the users to electrically disable the
internal USB port which contacts to BMC.
4861 USB PORT with
BMC This feature will allow the users to electrically enable the
internal USB port which contacts to BMC.
4870 Force PXE Boot
only
Disables PXE to be the boot device only.
4871 Force PXE Boot
only Enables PXE to be the boot device only. The system
retrying to boot from PXE device.
