128 | Using the System Setup Program
Token Setup option Description
4849 Onboard LAN
ASPM Controls the level of ASPM supported to on-board LAN.
L0s and L1 entry enabled.
484A Onboard LAN
ASPM Controls the level of ASPM supportedto on-board LAN.
L0s entry downstream enabled.
484B
Onboard LAN
ASPM
Controls the level of ASPM supported to on-board LAN.
L0s entry downstream and L1 enabled.
484C Mezzanine Slot
ASPM Controls the level of ASPM supported on Mezzanine Slot.
All entry disabled.
484D Mezzanine Slot
ASPM Controls the level of ASPM supported on Mezzanine Slot.
L0s entry enabled.
484E Mezzanine Slot
ASPM Controls the level of ASPM supported on Mezzanine Slot.
L1 entry enabled.
484F Mezzanine Slot
ASPM Controls the level of ASPM supported on Mezzanine Slot.
L0s and L1 entry enabled.
4850
Mezzanine Slot
ASPM
Controls the level of ASPM supported on Mezzanine Slot.
L0s entry downstream enabled.
4851 Mezzanine Slot
ASPM Controls the level of ASPM supported on Mezzanine Slot.
L0s entry downstream and L1 enabled.
4852 NB-SB Link
ASPM Controls the level of ASPM supported on the NB-SB. All
entry disabled.
4853
NB-SB Link
ASPM
Controls the level of ASPM supported on the NB-SB. L1
entry enabled.
4854 Maximum
Payload Size Auto detects the PCI-E maximum payload size.
4855
Maximum
Payload Size
Sets the PCI-E maximum payload size to 128 Bytes.
4856 Maximum
Payload Size Sets the PCI-E maximum payload size to 256 Bytes
4857 WHEA Support Disables Windows Hardware Error Architecture.
