120 | Using the System Setup Program
Token Setup option Description
0224 Embedded
Video Controller The embedded video controller is enabled, and it is the
primary video device.
0225 Embedded
Video Controller The embedded video controller is disabled.
022D Boot Mode Enables booting to Unified Extensible Firmware Interface
(UEFI) capable operating systems.
022E Boot Mode Enables booting to legacy mode, ensures compatibility
with operating systems that do not support UEFI.
0231 Active
Processor Cores All four cores of the processor are enabled. This is
applicable for Quad-core processor only.
0232 Active
Processor Cores Two cores of the processor are enabled. This is applicable
for Quad-core and Dual-core processors.
0233 Active
Processor Cores Single core of the processor is enabled. This is applicable
for Quad-core and Dual-Core processors.
024B C States Sets to enable (default), the processor can operate in all
available Power C States.
024C C States Sets to disable, there are no C states available for the
processor.
024D Pause on Errors Enables the BIOS from prompting for F1/F2 on error.
BIOS pauses at F1/F2 prompt.
024E Pause on Errors Disables the BIOS from prompting for F1/F2 on error.
BIOS pauses at F1/F2 prompt
024F Quiet Boot Enables the display of the splash or summary screen,
rather than the detail of the POST flow.
0250 Quiet Boot
Disables the display of the splash or summary screen. The
user is able to see the detail of the POST messages.
0251 N/A The first NIC is used for PXE boot, followed by NIC2.
0252 N/A The second NIC is used for PXE boot, followed by NIC1.
0254 3F8h/2F8h By default, set rear serial port address as 0x3F8 and
internal serial port address as 0x2F8.
