Example 1
If the SRN is 24002, the device is connected to adapter port 0 (shown as A1 on
the screen), and has an SSA address of 02 (shown as 2 on the screen). In the
example screen, that device is pdisk3, which is the first device of the two. The
second device is pdisk2 (PAA−1).
If the SRN is 33002, the first device of the two is again pdisk3. The second
device is pdisk4 (PAA+1).
LINK VERIFICATION
802386
SSA Link Verification for:
nunu:ssa0
00-04
IBM SSA 160 SerialRAID Adapter (
To Set or Reset Identify, move cursor onto selection, then press
Physical
Serial#
Adapter Port
A1 A2 B1 B2
Status
[TOP]
nunu:pdisk1
AC7AA09A
0
3
Good
nunu:pdisk2
AC7AA2D6
1
2
Good
nunu:pdisk3
AC7AA0BD
2
1
Good
nunu:pdisk4
AC7AA0B1
3
0
Good
F3=Cancel
F10=Exit
