5. (from step 4)

Observe the Status column on the screen. If the status of any pdisk is ‘Failed’, that
pdisk is failing. In the example shown here, pdisk2 is failing.

LINK VERIFICATION

802386

SSA Link Verification for:

nunu:ssa0

00-04

IBM SSA 160 SerialRAID Adapter (

To Set or Reset Identify, move cursor onto selection, then press .

Physical

Serial#

Adapter Port
A1 A2 B1 B2

Status

[TOP]

nunu:pdisk11

AC7AA09A

0

5

Good

nunu:pdisk8

AC7AA2D6

1

4

Good

nunu:pdisk2

AC7AA0BD

2

3

Failed

nunu:pdisk3

AC7AA0B1

3

2

Good

nunu:pdisk7

AC7AA0B5

4

1

Good

nunu:pdisk12

AC7AA052

5

0

Good

nunu:pdisk0

AC7AA0B9

0

5

Good

nunu:pdisk1

AC7AA0B3

1

4

Good

nunu:pdisk10

AC7AA0B4

2

3

Good

[MORE...4]

F3=Cancel

F10=Exit

Is one of the pdisks failing?

NO

Go to step 6 on page 449.

YES

a. Use the Identify function (as instructed on the screen) to find the failing

disk. See “Finding the Physical Location of a Device” on page 409 if
you need more information about finding the disk drive.

b. Exchange the disk drive for a new one (see “Exchanging Disk Drives”

on page 319).

c. Go to “MAP 2410: SSA Repair Verification” on page 475 to verify the

repair.

448

User’s Guide and Maintenance Information
