Normal Reconnection: When the systems are reconnected, the secondary disk
drives are resynchronized with the primary disk drives, as shown in Figure 33.
The array enters the Good state for both systems.
Split Array Resolution
= Primary
System 1
SSA Adapter
System 2
SSA Adapter
Secondary 1
Secondary 2
Primary 1
Primary 2
Split Array Resolution
= Primary
0011 0011
1111 0000 0011 0011
1111 1111
0000 1111
1010 1010 0000 1111
1010 1010
Figure 33. Reconnection of a Split Array
200 User’s Guide and Maintenance Information
