6. Refer to Figure 49.

7. Install the mounting screw

1

, and tighten it fully. (The screw is supplied with the

Fast-Write Cache Option Card.)

8. Reinstall the adapter into the using system (see the Installation and Service Guide

for the using system).

Note: The battery on the Fast-Write Option Card is not fully charged. After the

adapter is connected to the power, initial battery charging completes in 5 to
60 minutes. During this time, the fast-write disks can be enabled and used,
but the fast-write function remains inactive. To determine whether the
fast-write cache is active or inactive, give the command:

ssa_fw_status -a ssaX -c

1

Figure 49. Installing the Mounting Screw of the Fast-Write Cache Option Card

Chapter 15. Removal and Replacement Procedures

335

|
|
|
|
|

|
