4. Select a second disk drive if required (for example, pdisk5). The following display
appears again:
SET SERVICE MODE 802382
systemname:pdisk5 AC7C6E51 4GB SSA C Physical Disk Drive
Move cursor onto selection, then press .
+ Set or Reset Identify.
Select this option to set or reset the Identify indicator
on the disk drive.
> Set or Reset Service Mode.
Select this option to set or reset Service Mode on the
disk drive.
ENSURE THAT NO OTHER HOST SYSTEM IS USING THIS DISK DRIVE
BEFORE SELECTING THIS OPTION.
F3=Cancel F10=Exit
5. Select Service Mode or the Identify function. If the original disk drive is to remain in
Service Mode, you can select only the Identify function now. (Only one disk drive at
a time can be in Service Mode.) The list of pdisks appears again. The pdisk that is
in Identify Mode is identified by a +.
SET SERVICE MODE 802381
Move cursor onto selection, then press .
systemname:pdisk0 AC50AE43 2GB SSA C Physical Disk Drive
systemname:pdisk1 AC706EA3 2GB SSA C Physical Disk Drive
systemname:pdisk2 AC1DBE11 2GB SSA C Physical Disk Drive
> systemname:pdisk3 AC1DBEF4 2GB SSA C Physical Disk Drive
systemname:pdisk4 AC50AE58 2GB SSA C Physical Disk Drive
+ systemname:pdisk5 AC7C6E51 2GB SSA C Physical Disk Drive
systemname:pdisk6 AC706E9A 2GB SSA C Physical Disk Drive
systemname:pdisk7 AC1DEEE2 2GB SSA C Physical Disk Drive
systemname:pdisk8 AC1DBE32 2GB SSA C Physical Disk Drive
F3=Cancel F10=Exit
6. Identify other disk drives in the same way, if required.
382 User’s Guide and Maintenance Information
