5–19 Programming
This group of parameters contains internally stored frequency settings.
Frequency Set
[Freq Select 1]
This parameter controls which of the frequency
sources is currently supplying the
[Freq Command] to the drive unless
[Freq Select 2] or [Preset Freq 1-7] is selected.
Refer to the Speed Select Input Table in Chapter 2.
Parameter Number 5
Parameter Type Read and Write
Factory Default “Adapter 1”
Units Display Drive
“Adapter 1” 6
“Adapter 2” 7
“Adapter 3” 8
“Adapter 4” 9
“Adapter 5” 10
“Adapter 6” 11
“Preset 1-7” 12-18
“Use Last” 0
“Remote Pot” 1
“0-10 Volt” 2
“4-20 mA” 3
“Pulse Ref” 4 Refer to [Pulse/Enc Scale] Scale Value
“MOP” 5
[Freq Select 2]
This parameter controls which of the frequency
sources is currently supplying the
[Freq Command] to the drive unless
[Freq Select 1] or [Preset Freq 1-7] is selected.
Refer to the Speed Select Input Table in Chapter 2.
Parameter Number 6
Parameter Type Read and Write
Factory Default “Preset 1”
Units Display Drive
“Adapter 1” 6
“Adapter 2” 7
“Adapter 3” 8
“Adapter 4” 9
“Adapter 5” 10
“Adapter 6” 11
“Preset 1-7” 12-18
“Use Last” 0
“Remote Pot” 1
“0-10 Volt” 2
“4-20 mA” 3
“Pulse Ref” 4 Refer to [Pulse/Enc Scale] Scale Value
“MOP” 5
[Jog Frequency]
This parameter sets the frequency the drive will
output when it receives a valid jog command.
Parameter Number 24
Parameter Type Read and Write
Display Units / Drive Units 0.1 Hertz / Hertz x 100
Factory Default 10.0 Hz
Minimum Value 0.0 Hz
Maximum Value 400.0 Hz
[Preset Freq 1-7]
These values set the frequencies that the drive will
output when selected. Refer to Speed Select Input
table in Chapter 2.
Parameter Number(s) 27-29 & 73-76
Parameter Type Read and Write
Display Units / Drive Units 0.1 Hertz / Hertz x 100
Factory Default 0.0 Hz
Minimum Value 0.0 Hz
Maximum Value 400.0 Hz
