Chapter
1
Information and Precautions
Chapter 1 provides information on the general intent of this manual,
gives an overall description of the 1336 PLUS Adjustable Frequency
AC Drive and provides a listing of key drive features.
This publication provides planning, installation, wiring and
diagnostic information for the 1336 PLUS Drive. To assure
successful installation and operation, the material presented must be
thoroughly read and understood before proceeding. Particular
attention must be directed to the Attention and Important statements
contained within.
!
ATTENTION: To guard against machine damage
and/or personal injury, drives with ratings above 45 kW
(60 HP) must not be used with software versions below
1.07. Refer to table below.
Three-Phase Drive Rating
1
Compatible with
Frame
200-240V
380-480V
500-600V
Compatible with
Version . . .
Frame
Reference
0.37-0.75 kW
0.5-1 HP
0.37-1.2 kW
0.5-1.5 HP
–
1.05 & Up or
1.06 w/std. Jog
2
A1
1.2-1.5 kW
1.5-2 HP
1.5-2.2 kW
2-3 HP
–
1.05 & Up or
1.06 w/std. Jog
2
A2
2.2-3.7 kW
3-5 HP
3.7 kW
5 HP
–
1.05 & Up or
1.06 w/std. Jog
2
A3
–
5.5-7.5 kW
7.5-10 HP
0.75-3.7 kW
1-5 HP
3.01 & Up (380-480V)
3.02 & Up (500-600V)
A4
5.5-11 kW
7.5-15 HP
5.5-22 kW
7.5-30 HP
5.5-15 kW
7.5-20 HP
1.05 & Up or
1.06 w/std. Jog
2
B1/B2
15-22 kW
20-30 HP
30-45 kW
40-60 HP
18.5-45 kW
25-60 HP
1.05 & Up or
1.06 w/std. Jog
2
C
30-45 kW
40-60 HP
45-112 kW
60-150 HP
56-93 kW
75-125 HP
2.01 & Up
D
56-93 kW
75-125 HP
112-187- kW
150-250 HP
112-187 kW
150-250 HP
2.01 & Up
E
–
112-336- kW
250-450 HP
187-336 kW
250-450 HP
4.01 & Up
F
–
187-448 kW
250-600 HP
224-448 kW
300-600 HP
2.01 & Up
G
1
kW and HP are constant torque.
2
See pages 2–28 and 2–29.
Manual Objectives
Software Compatibility
