B–7 Dimensions
IP 65/54 (NEMA Type 4/12) Dimensions
Typical Top and Bottom
Detail A
See Detail A
See
Detail B
A
D F G
H
C
E B
12.7 (0.50)
12.4 (0.49)
7.9 (0.31)
Frame
Reference
A1
A2
A3
A4
B1
B2
C
A
430.0
(16.93)
430.0
(16.93)
430.0
(16.93)
655.0
(25.79)
655.0
(25.79)
655.0
(25.79)
655.0
(25.79)
B
525.0
(20.67)
525.0
(20.67)
525.0
(20.67)
650.0
(25.59)
650.0
(25.59)
900.0
(35.43)
1200.0
(47.24)
C
350.0
(13.78)
350.0
(13.78)
350.0
(13.78)
425.0
(16.74)
425.0
(16.74)
425.0
(16.74)
425.0
(16.74)
E
500.1
(19.69)
500.1
(19.69)
500.1
(19.69)
625.1
(24.61)
625.1
(24.61)
875.0
(34.45)
1174.5
(46.22)
D
404.9
(15.94)
404.9
(15.94)
404.9
(15.94)
629.9
(24.80)
629.9
(24.80)
629.9
(24.80)
629.9
(24.80)
F
250.0
(9.84)
250.0
(9.84)
250.0
(9.84)
293.0
(11.54)
293.0
(11.54)
293.0
(11.54)
293.0
(11.54)
G
N/A
N/A
N/A
63.5
(2.50)
63.5
(2.50)
63.5
(2.50)
63.5
(2.50)
H
N/A
N/A
N/A
76.2
(3.00)
76.2
(3.00)
76.2
(3.00)
76.2
(3.00)
All Dimensions in Millimeters and (Inches)
7.1 (0.28) Dia.
12.7 (0.50)
12.7 (0.50) Dia.
14.3 (0.56) Dia.
Drive
Heatsink
Detail B
19.1 (0.75) 19.1 (0.75) Dia.
5.5 kW (7.5 HP) at 200-240V AC
5.5-11 kW (7.5-15 HP) at 380-480V AC
5.5-7.5 kW (7.5-10 HP) at 500-600V AC
7.5-11 kW (10-15 HP) at 200-240V AC
15-22 kW (20-30 HP) at 380-480V AC
11-15 kW (15-20 HP) at 500-600V AC
Approx. Ship
Weight
16.8 kg
(37.0 lbs.)
17.9 kg
(39.4 lbs.)
18.6 kg
(41.0 lbs.)
39.5 kg
(87.0 lbs.)
44.7 kg
(98.5 lbs.)
56.5 kg
(124.5 lbs.)
80.7 kg
(178.0 lbs.)
