A–16 Specifications and Supplemental Information
When using a Series B HIM, the parameters listed can be uploaded
to the HIM for downloading to other drives.
No. Name Setting No. Name Setting No. Name Setting No. Name Setting
5 Freq Select 1
6 Freq Select 2
7 Accel Time 1
8 Decel Time 1
9 DC Boost Select
9 Control Select
10 Stop Select 1
11 Bus Limit En
12 DC Hold Time
13 DC Hold Level
14 Run On Power Up
15 Reset/Run Time
16 Minimum Freq
17 Base Frequency
18 Base Voltage
19 Maximum Freq
20 Maximum Voltage
21 Input Mode
22 MOP Increment
24 Jog Frequency
25 Analog Out Sel
27 Preset Freq 1
28 Preset Freq 2
29 Preset Freq 3
30 Accel Time 2
31 Decel Time 2
32 Skip Freq 1
33 Skip Freq 2
34 Skip Freq 3
35 Skip Freq Band
36 Current Limit
37 Overload Mode
38 Overload Amps
39 Flt Clear Mode
40 Line Loss Fault
41 Motor Type
42 Slip @ F.L.A.
43 Dwell Frequency
44 Dwell Time
45 PWM Frequency
46 Pulse/Enc Scale
47 Language
48 Start Boost
49 Break Frequency
50 Break Voltage
52 Stop Select 2
56 S Curve Time
57 S Curve Enable
73 Preset Freq 4
74 Preset Freq 5
75 Preset Freq 6
76 Preset Freq 7
77 Speed Control
78 Traverse Period
79 Max Traverse
80 P Jump
81 Blwn Fuse Flt
82 Cur Lim Trip En
83 Run Boost
84 Analog Invert
85 Reset/Run Tries
90 Analog Trim En
91 Low Bus Fault
92 Logic Mask
93 Local Mask
94 Direction Mask
95 Start Mask
96 Jog Mask
97 Reference Mask
98 Accel Mask
99 Decel Mask
100 Fault Mask
101 MOP Mask
111 Data In A1
112 Data In A2
113 Data In B1
114 Data In B2
115 Data In C1
116 Data In C2
117 Data In D1
118 Data In D2
119 Data Out A1
120 Data Out A2
121 Data Out B1
122 Data Out B2
123 Data Out C1
124 Data Out C2
125 Data Out D1
126 Data Out D2
127 Process 1 Par
128 Process 1 Scale
129 Process 1 Txt 1
130 Process 1 Txt 2
131 Process 1 Txt 3
132 Process 1 Txt 4
133 Process 1 Txt 5
134 Process 1 Txt 6
135 Process 1 Txt 7
136 Process 1 Txt 8
150 4-20 mA Loss Sel
151 Maximum Speed
152 Encoder Type
154 Anlg Out Offset
155 Flying Start En
156 FStart Forward
157 FStart Reverse
158 Digital Out Sel
158 CR1 Out Select
159 Dig Out Freq
160 Dig Out Current
161 Dig Out Torque
165 Speed KI
169 Run/Accel Boost
169 Boost Slope
174 CR2 Out Select
175 CR3 Out Select
176 CR4 Out Select
177 Motor NP RPM
178 Motor NP Hertz
180 Process 2 Par
181 Process 2 Scale
182 Process 2 Txt 1
183 Process 2 Txt 2
184 Process 2 Txt 3
185 Process 2 Txt 4
186 Process 2 Txt 5
187 Process 2 Txt 6
188 Process 2 Txt 7
189 Process 2 Txt 8
190 Motor NP Volts
191 Motor NP Amps
192 KI Amps
192 Flux Amps Ref
193 KP Amps
194 IR Drop Volts
195 Slip Comp Gain
200 Flux Up Time
201 Motor OL Fault
203 VT Scaling
204 Ground Warning
206 Alarm Mask
213 PI Config
215 PI Ref Select
216 PI Fdbk Select
221 KI Process
222 KP Process
223 PI Neg Limit
224 PI Pos Limit
225 PI Preload
226 Shear Pin Fault
227 Adaptive I Lim
228 LLoss FStart
229 Freq Ref SqRoot
230 Save MOP Ref
231 Hold Level Sel
232 Current Lmt Sel
233 Abs Analog Out
234 Set Anlg Out Lo
235 Set Anlg Out Hi
237 Set 0-10 Vlt Lo
238 Set 0-10 Vlt Hi
239 Set 4-20 mA Lo
240 Set 4-20 mA Hi
Read/Write Parameter
Record
