B–2 Dimensions
IP 20 (NEMA Type 1) Dimensions – Frames A1 through A4
All Dimensions in Millimeters and (Inches)
All Weights in Kilograms and (Pounds)
C Max. D
A
Y
CC
E B
Z
BB
AA
A
215.9
(8.50)
215.9
(8.50)
215.9
(8.50)
260.0
(10.24)
B
290.0
(11.42)
290.0
(11.42)
290.0
(11.42)
350.0
(13.78)
C Max.
160.0
(6.30)
180.5
(7.10)
207.0
(8.15)
212.0
(8.35)
D
185.2
(7.29)
185.2
(7.29)
185.2
(7.29)
230.0
(9.06)
E
275.0
(10.83)
275.0
(10.83)
275.0
(10.83)
320.0
(12.60)
Y
15.35
(0.60)
15.35
(0.60)
15.35
(0.60)
15.35
(0.60)
Z
7.5
(0.30)
7.5
(0.30)
7.5
(0.30)
15.35
(0.60)
AA
130.0
(5.12)
130.0
(5.12)
130.0
(5.12)
130.0
(5.12)
BB
76.2
(3.00)
76.2
(3.00)
76.2
(3.00)
133.0
(5.23)
CC
85.3
(3.36)
85.3
(3.36)
85.3
(3.36)
86.0
(3.39)
Shipping
Weights
4.31 kg
(9.5 lbs.)
5.49 kg
(12.1 lbs.)
6.71 kg
(14.8 lbs.)
15.90 kg
(35.0 lbs.)
Mounting Holes (4) – See Detail
7.0 (0.28)
7.0 (0.28)
12.7 (0.50)
12.7 (0.50)
Mounting Hole Detail
Three-Phase Rating 1, 2
200-240V
0.37-0.75 kW
0.5-1 HP
1.2-1.5 kW
1.5-2 HP
2.2-3.7 kW
3-5 HP
–
5.5-11 kW
7.5-15 HP
15-22 kW
20-30 HP
30-45 kW
40-60 HP
56-93 kW
75-125 HP
–
–
380-480V
0.37-1.2 kW
0.5-1.5 HP
1.5-2.2 kW
2-3 HP
3.7 kW
5 HP
5.5-7.5 kW *
7.5-10 HP
5.5-22 kW *
7.5-30 HP
30-45 kW
40-60 HP
45-112 kW
60-150 HP
112-187 kW
150-250 HP
187-336 kW
250-450 HP
187-448 kW
250-600 HP
500-600V
–
–
–
0.75-3.7 kW
1-5 HP
5.5-15 kW
7.5-20 HP
18.5-45 kW
25-60 HP
56-93 kW
75-125 HP
112-187 kW
150-250 HP
187-336 kW
250-450 HP
224-448 kW
300-600 HP
Frame
Reference
A1
A2
A3
A4
B1/B2
C
D
E
F
G
Frame
Reference
A1
A2
A3
A4
Bottom View Will Vary with HP – See Bottom View Dimensions
Use care when choosing Frame Reference - Some ratings may
exist in another frame size. *
1 Refer to Chapter 1 for catalog numbers and Appendix for derating info. 2 kW/HP are constant torque (CT) ratings.
