5–38 Programming
This group contains a number of “Read Only” parameters that display drive operating char-
acteristics. This group will only be available with firmware versions 2.01 and above. Refer
to the “Diagnostics” group if your firmware is below 2.01.
Ratings
[Drive Type]
This parameter displays a decimal number which
can be translated into the drive catalog number by
using the adjacent chart. Refer to Chapter 1 for an
explanation of the catalog numbers.
Parameter Number 61
Parameter Type Read Only
Display 1336S– . . .
8449 AQF05
8450 AQF07
8451 AQF10
8452 AQF15
8453 AQF20
8454 AQF30
8455 AQF50
12552 A007
12553 A010
12554 A015
12555 A020
12556 A025
12557 A030
12558 A040
12559 A050
12560 A060
12561 A075
12562 A100
12563 A125
8705 BRF05
8706 BRF07
Display 1336S– . . .
8707 BRF10
8708 BRF15
8709 BRF20
8710 BRF30
8711 BRF50
8712 BRF75
8713 BRF100
12808 B007
12809 B010
12810 B015
12811 B020
12812 B025
12813 B030
12824 BX040
12814 B040
12815 B050
12816 BX060
12825 B060
12817 B075
12818 B100
12819 B125
Display 1336S– . . .
12826 BX150
12820 B150
12821 B200
12827 B250
12838 BP250
12828 BX250
12829 B300
12839 BP300
12822 B350
12840 BP350
12830 B400
12841 BP400
12832 B450
12842 BP450
12823 B500
12833 B600
8963 CWF10
8965 CWF20
8966 CWF30
8967 CWF50
13064 C007
Display 1336S– . . .
13065 C010
13066 C015
13067 C020
13068 C025
13069 C030
13070 C040
13071 C050
13072 C060
13073 C075
13074 C100
13075 C125
13076 C150
13077 C200
13083 C250
13091 CX300
13085 C300
13078 C350
13086 C400
13088 C450
13079 C500
13089 C600
[Firmware Ver.]
This parameter displays the version number of the
drive firmware.
Parameter Number 71
Parameter Type Read Only
Display Units / Drive Units None / Version x 100
Display 0.00
[Drive Rtd Volts]
This parameter displays the rated input voltage of
the drive.
Parameter Number 147
Parameter Type Read Only
Display Units / Drive Units 1 Volt / Volts
Display Drive Rated Input Voltage
[Rated Amps]
This parameter displays the rated output current of
the drive.
Parameter Number 170
Parameter Type Read Only
Display Units / Drive Units 0.1 Amp / Amps x 10
Display Drive Rated Output Amps
[Rated kW]
This parameter displays the rated kW of the drive.
Parameter Number 171
Parameter Type Read Only
Display Units / Drive Units kW / kW x 100
Display Drive Rated Output kW
[Rated CT Amps]
This parameter displays the rated output current of
the drive.
Parameter Number 148
Parameter Type Read Only
Display Units / Drive Units 0.1 Amp / Amps x 10
Display Drive Rated Output Amps
