Rockwell Automation 1336S Plus FRN 1.xx-5.xx User Manual
Page 161
B–5
Dimensions
IP 20 (NEMA Type 1) & Open Dimensions – Frame F
2286.0
(90.00)
762.0
(30.00)
252.7
(9.95)
635.0
(25.00)
Open Chassis
487.7 (19.20)
37.9
(1.49)
274.8
(10.82)
193.0
(7.60)
1219.2
(48.00)
All Dimensions in Millimeters and (Inches)
Conduit
Access Area
Bottom View
31.5
(1.24)
698.5
(27.50)
298.5
(11.75)
50.8
(2.00)
Approximate Shipping Weight (drive & pallet):
415.0 kg (915 lbs.)
