5–37 Programming
[Output Pulses]
This parameter displays the number of output cycles
for the PWM waveform. The count rolls over at
65535.
Parameter Number 67
Parameter Type Read Only
Display Units / Drive Units 1 Pulse / Pulses
Factory Default None
Minimum Value 0
Maximum Value 65535
[Current Angle]
Firmware Version 3.04 and below
This parameter displays the angle, in degrees, of
displacement between output voltage and output
current. The cosine of this number is an
approximation of output power factor.
Firmware Version 4.01 and higher
This parameter has no function.
Parameter Number 72
Parameter Type Read Only
Display Units / Drive Units 1 Deg / 255 = 360 Deg
Factory Default None
[Heatsink Temp]
This parameter displays the heatsink temperature.
Parameter Number 70
Parameter Type Read Only
Display Units / Drive Units 1
°
C / Deg. C
Factory Default None
Minimum Value 0
Maximum Value 255
°
C
[Set Defaults]
Setting this parameter to “Defaults Init” resets all
parameters to their factory values.
Parameter Number 64
Parameter Type Read and Write
Factory Default “Ready”
Units Display Drive
“Ready” 0 Display after function complete.
“Store to EE” 1
“Rcll frm EE” 2
“Default Init” 3 Resets all parameters to factory
settings.
[DC Bus Memory]
This parameter displays the nominal DC bus voltage
level. This value is used to determine line loss,
overvoltage, decel frequency and other points.
Parameter Number 212
Parameter Type Read Only
Display Units / Drive Units 1 Volt / Volts
Display Volts
[EEPROM Cksum] –Firmware 4.01 & later
The value of this parameter provides a checksum
value that indicates a change in drive programming
has occurred.
Parameter Number 172
Parameter Type Read Only
Display Units / Drive Units None
Diagnostics
