3–9

Human Interface Module

EEProm Mode

Reset Defaults

The EEProm mode is used to restore all
settings to factory default values or upload/
download parameters between the HIM and
drive (Series B HIM, Only).

1. To restore factory defaults:

A. From the Status Display, press Enter

(or any key). “Choose Mode” will be
displayed.

B. Press the Increment (or Decrement)

key until “EEProm” is displayed. If
EEProm is not in the menu, program-
ming is password protected. Refer to
Password Mode later in this section.

C. Press Enter.

D. Press the Increment (or Decrement)

key until “Reset Defaults” is dis-
played.

E. Press Enter to restore all parameters to

their original factory settings.

F. Press ESC. “Reprogram Fault” will

display.

G. Press the Stop key to reset the fault.

Important: If [Input Mode] was pre-
viously set to a value other than “1,”
cycle drive power to reset.

Stopped

+0.00 Hz

Choose Mode
Display

Choose Mode
EEProm

EEProm
Reset Defaults

Reprogram Fault
F 48

Drive –> HIM

2. To upload a parameter profile from the

drive to the HIM, you must have a Series
B HIM.

A. From the EEProm menu (see steps

A-C above), press the Increment/
Decrement keys until “Drive –> HIM”
is displayed.

B. Press Enter. A profile name (up to 14

characters) will be displayed on line 2
of the HIM. This name can be changed
or a new name entered. Use the SEL
key to move the cursor left. The
Increment/Decrement keys will change
the character.

EEProm
Drive –> HIM

Drive –> HIM
1 A
