Chapter 8 Configuring Recorders
Configuring Device Memory
PM180 Substation Automation Unit
81
Option
Format/Range Description
Record size
Shows the size of the file record for a single channel or
section. It is set automatically depending on the file and
on the number of parameters in the data record
Parameters
Defines the number of parameters in a single data
record for data log files.
Memory is allocated for each file statically and does not change unless you re-
organize the files. The PM180 automatically performs de-fragmentation of the
memory each time the file allocation changes. This helps keep all free memory in one
continuous block, and thus prevents possible leakage of memory caused by
fragmentation.
In the EN 50160 version, data log files #9 and #10 are automatically configured for
recording EN 51060 compliance statistics and harmonics survey data. You may not
change the record structure, but can change the amount of memory allocated for
each file.
Data log files #15 and #16 may be configured to record TOU monthly profile and
TOU daily profile data on a daily or monthly basis.
To change the file properties or to create a new file:
1. Double click on the file partition you want to change, or
highlight the file row, and then click on the “Configure File”
button.
2. To change the file properties, select desired parameters, and
then click OK. For your reference, the record size and the
number of records available for the file are reported in the
dialog box.
3. To delete a file partition, click on Delete, and then click OK.
4. Send your new setup to the device.
The following table shows how to calculate a file size for different files.
File
Record Size, Bytes
File Size, Bytes
Event Log
20
Record Size
Number of Records
Data Log
12 + 4
Number of
Parameters
Record Size
Number of Records
EN50160 Compliance Statistics
(Data log #9)
152 (per channel)
12
Record size
Number of records
EN50160 Harmonics Survey
(Data log #10)
224 (per channel)
3
Record size
Number of records
TOU Profile Log
(Data log #15-#16)
12 + 4
Number of
Season Tariffs
Record Size
Number of TOU
Registers
Number of Records x 2
Waveform Log
1072
Record Size
Number of Channels
Number of Series
Number of
Records per Series
SOE Log
16
Record Size
Number of Records
PQ Log
32
Record Size
Number of Records
Fault Log
44
Record Size
Number of Records
For more information on configuring specific files, see following sections.
The device memory is pre-configured for regular data trending and fault recording
applications as shown in the following table.
No. File
Type
Size,
Bytes
Sections/
Channel
Max. of
Records
Max. of
Events
Description
1
Event log
Wrap
around
40000
2000
2000
2
Data log #1 Wrap
around
3072000
38400
38400
Configured for
continuous data
recording
3
Data log #2 Wrap
around
3072000
38400
38400
Configured for
continuous data
recording
