‎Chapter 3 Using the RDM Configuring the RDM
PM180 Substation Automation Unit 33
1. If the StA window is not a current active window, use the SELECT key to
activate it.
2. Press the SELECT key to enter the Status Information Display
For viewing the RDM or the PM180 setup options:
1. Press the SELECT key to activate the OPS window.
2. Press the SELECT key to enter the Setup Options Menu.
To change the RDM or the PM180 setup, or to clear the accumulated
values:
1. Press the SELECT key to activate the CHG window.
2. Press the SELECT key to enter the Setup Options Menu.
Entry to this menu can be password protected.
After entering either OPS or CHG menu, the list of setup menus is
displayed in the upper window as shown at left. Use the Up/Down keys
to scroll through the menus. Press ENTER to enter the selected menu.
Entering a Password
The setup menus can be secured by a user-defined 8 digits password.
The device is shipped with password protection disabled. To enable
password protection or to change a password, see
Access Control
Menu .
If authorization is required, the Password menu appears as shown left.
To change the RDM or the PM180 setup, or to clear the accumulated
values:
1. Set the first digit using the Up/Down arrow keys.
2. Press SELECT to advance to the next digit.
3. Set the other password digits in the same manner.
4. Press ENTER to confirm the password.
If the password entered is incorrect, you are returned to the previous
menu.
Entering Numbers
To change a number in the active (flashing) window, use the Up/Down
arrow keys. If you press and release the arrow key, the value is
incremented or decremented by one. If you press and hold the key, the
value in the window is updated approximately twice per second. If you
hold the key for more than 5 seconds, the position of the digit being
changed moves to the adjacent higher digit.
To accept the new value, press ENTER.
To abort changes, press ESC.
Configuring the RDM
To change communication or display options for your RDM, select
“diSP” from the menu list.
The following table lists available display options, their default settings
and ranges.
Label Option Range Default Description
rESEt
ESC
PASS
0000
0000
SELECT
ENERGY
ENTER
ENERGY
ENTER CHG
 diSP
bASc
200.0
Pt
diSP
1.0
UPdt
