‎Appendix D EN50160 Statistics Log Files
178 PM180 Substation Automation Unit
Field
No. Designation Description
16 V1 N1 Total number of incidents on phase V1
17 V1 Max Maximum voltage magnitude on phase V1
18 V2 N1 Total number of incidents on phase V2
19 V2 Max Maximum voltage magnitude on phase V2
20 V3 N1 Total number of incidents on phase V3
21 V3 Max Maximum voltage magnitude on phase V3
Transient Overvoltages (indicative statistics)
1 N1 110% Number of polyphase incidents u>120%
2 N2 150% Number of polyphase incidents u>150%
3 N3 200% Number of polyphase incidents u>200%
4 N4 250% Number of polyphase incidents u>250%
5 N5 300% Number of polyphase incidents u>300%
6 V1 N1 110% Number of incidents u>120% on phase V1
7 V1 N2 150% Number of incidents u>150% on phase V1
8 V1 N3 200% Number of incidents u>200% on phase V1
9 V1 N4 250% Number of incidents u>250% on phase V1
10 V1 N5 300% Number of incidents u>300% on phase V1
11 V2 N1 110% Number of incidents u>120% on phase V2
12 V2 N2 150% Number of incidents u>150% on phase V2
13 V2 N3 200% Number of incidents u>200% on phase V2
14 V2 N4 250% Number of incidents u>250% on phase V2
15 V2 N5 300% Number of incidents u>300% on phase V2
16 V3 N1 110% Number of incidents u>120% on phase V3
17 V3 N2 150% Number of incidents u>150% on phase V3
18 V3 N3 200% Number of incidents u>200% on phase V3
19 V3 N4 250% Number of incidents u>250% on phase V3
20 V3 N5 300% Number of incidents u>300% on phase V3
21 V1 Peak Max Maximum peak voltage on phase V1
22 V2 Peak Max Maximum peak voltage on phase V2
23 V3 Peak Max Maximum peak voltage on phase V3
Supply Voltage Unbalance
1 Nnv Number of non-valid 10-min intervals
2 N Number of valid 10-min intervals
3 N1 Number of incidents V Unb > 2%, N1
4 N1/N, % EN50160 compliance ratio, N1/N
5 V Unb% Max Maximum voltage unbalance
Harmonic Voltage
1 Nnv Number of non-valid 10-min intervals
2 N Number of valid 10-min intervals
3 N1 Number of polyphase harmonic voltage incidents, N1
4 N2 Number of polyphase voltage THD incidents, N2
5 N1/N, % EN50160 harmonic voltage compliance ratio, N1/N
6 N2/N, % EN50160 voltage THD compliance ratio, N2/N
7 V1 N1 Number of harmonic voltage incidents on phase V1
8 V1 N2 Number of voltage THD incidents on phase V1
9 V1 HD% Max Worst-case harmonic magnitude on phase V1, %Un
10 V1 H# Worst-case harmonic component number on phase V1
11 V1 THD Max Worst-case voltage THD on phase V1
12 V2 N1 Number of harmonic voltage incidents on phase V2
13 V2 N2 Number of voltage THD incidents on phase V2
14 V2 HD% Max Worst-case harmonic magnitude on phase V2, %Un
15 V2 H# Worst-case harmonic component number on phase V2
16 V2 THD Max Worst-case voltage THD on phase V2
17 V3 N1 Number of harmonic voltage incidents on phase V3
18 V3 N2 Number of voltage THD incidents on phase V3
