‎Appendix D EN50160 Statistics Log Files
180 PM180 Substation Automation Unit
Field
No. Designation Description
2 THDO MAX Maximum odd harmonics THD
3 THDE MAX Maximum even harmonics THD
4 %HD02 MAX Maximum H02 harmonic voltage magnitude, %Un
5 %HD03 MAX Maximum H03 harmonic voltage magnitude, %Un
… …
52 %HD50 MAX Maximum H50 harmonic voltage magnitude, %Un
V2 Harmonic Voltage
1 THD MAX Maximum THD
2 THDO MAX Maximum odd harmonics THD
3 THDE MAX Maximum even harmonics THD
4 %HD02 MAX Maximum H02 harmonic voltage magnitude, %Un
5 %HD03 MAX Maximum H03 harmonic voltage magnitude, %Un
… …
52 %HD50 MAX Maximum H50 harmonic voltage magnitude, %Un
V3 Harmonic Voltage
1 THD MAX Maximum THD
2 THDO MAX Maximum odd harmonics THD
3 THDE MAX Maximum even harmonics THD
4 %HD02 MAX Maximum H02 harmonic voltage magnitude, %Un
5 %HD03 MAX Maximum H03 harmonic voltage magnitude, %Un
… …
52 %HD50 MAX Maximum H50 harmonic voltage magnitude, %Un
