‎Appendix C Parameters for Monitoring and Data Logging
PM180 Substation Automation Unit 171
Designation Description
kW MAX Total kW
kvar MAX Total kvar
kVA MAX Total kVA
PF MAX Total PF
PF LAG MAX Total PF lag
PF LEAD MAX Total PF lead
MAX AUX Maximum 1-Cycle Auxiliary Values
I4 MAX I4 current
In MAX In current
FREQ MAX Frequency
V UNB% MAX Voltage unbalance
I UNB% MAX Current unbalance
VDC MAX DC voltage
V4 MAX V4 voltage
I4x MAX I4x current
V4 THD MAX V4 THD
I4 THD MAX I4x THD
I4 TDD MAX I4x TDD
MAX DMD Maximum Demands
V1 DMD MAX V1/V12 Maximum volt demand 1
V2 DMD MAX V2/V23 Maximum volt demand 1
V3 DMD MAX V3/V31 Maximum volt demand 1
I1 DMD MAX I1 Maximum ampere demand
I2 DMD MAX I2 Maximum ampere demand
I3 DMD MAX I3 Maximum ampere demand
kW IMP SD MAX Maximum kW import sliding window demand
kvar IMP SD MAX Maximum kvar import sliding window demand
kVA IMP SD MAX Maximum kVA sliding window demand
kvar IMP SD MAX Maximum kW export sliding window demand
kvar EXP SD MAX Maximum kvar export sliding window demand
V4 DMD MAX V4 Maximum volt demand
I4 DMD MAX I4 Maximum ampere demand
In DMD MAX In Maximum ampere demand
MAX HRM DMD Maximum Harmonic Demands
V1 THD DMD MAX V1/V12 THD demand 1
V2 THD DMD MAX V2/V23 THD demand 1
V3 THD DMD MAX V3/V31 THD demand 1
V4 THD DMD MAX V4 THD demand
I1 THD DMD MAX I1 THD demand
I2 THD DMD MAX I2 THD demand
I3 THD DMD MAX I3 THD demand
I4 THD DMD MAX I4 THD demand
I1 TDD DMD MAX I1 TDD demand
I2 TDD DMD MAX I2 TDD demand
I3 TDD DMD MAX I3 TDD demand
I4 TDD DMD MAX I4 TDD demand
MAX SUMMARY DMD Maximum Summary (TOU Total) Demands
SUM REG1 DMD MAX Summary register #1 maximum demand
SUM REG2 DMD MAX Summary register #2 maximum demand
… …
SUM REG16 DMD MAX Summary register #16 maximum demand
MAX PRG Programmable Min/Max Maximum Registers
PROG REG1 MAX Min/Max Register #1
PROG REG1 MAX Min/Max Register #2
… …
PROG REG16 MAX Min/Max Register #16
