‎Appendix C Parameters for Monitoring and Data Logging
172 PM180 Substation Automation Unit
Designation Description
ANALOG INPUTS Scaled Analog Inputs (Engineering Units)
AI1 Analog input AI1
AI2 Analog input AI2
…
AI16 Analog input AI16
AI RAW Raw Analog Inputs (A/D Units)
AI1 RAW Analog input AI1
AI2 RAW Analog input AI2
…
AI16 RAW Analog input AI16
AO RAW Raw Analog Outputs (A/D Units)
AO1 Analog output AO1
AO2 Analog output AO2
…
AO16 Analog output AO16
TOU PRMS TOU Parameters
ACTIVE TARIFF Active TOU tariff
ACTIVE PROFILE Active TOU profile
TOU REG1 TOU Energy Register #1
TOU REG1 TRF1 Tariff #1 register
TOU REG1 TRF2 Tariff #2 register
… …
TOU REG1 TRF16 Tariff #16 register
TOU REG2 TOU Energy Register #2
TOU REG2 TRF1 Tariff #1 register
TOU REG2 TRF2 Tariff #2 register
… …
TOU REG2 TRF16 Tariff #16 register
TOU REG3 TOU Energy Register #3
TOU REG3 TRF1 Tariff #1 register
TOU REG3 TRF2 Tariff #2 register
… …
TOU REG3 TRF16 Tariff #16 register
TOU REG4 TOU Energy Register #4
TOU REG4 TRF1 Tariff #1 register
TOU REG4 TRF2 Tariff #2 register
… …
TOU REG4 TRF16 Tariff #16 register
TOU REG5 TOU Energy Register #5
TOU REG5 TRF1 Tariff #1 register
TOU REG5 TRF2 Tariff #2 register
… …
TOU REG5 TRF16 Tariff #16 register
TOU REG6 TOU Energy Register #6
TOU REG6 TRF1 Tariff #1 register
TOU REG6 TRF2 Tariff #2 register
… …
TOU REG6 TRF16 Tariff #16 register
TOU REG7 TOU Energy Register #7
TOU REG7 TRF1 Tariff #1 register
TOU REG7 TRF2 Tariff #2 register
… …
TOU REG7 TRF16 Tariff #16 register
TOU REG8 TOU Energy Register #8
TOU REG8 TRF1 Tariff #1 register
TOU REG8 TRF2 Tariff #2 register
