‎Chapter 3 Using the RDM Configuring the PM180
PM180 Substation Automation Unit 39
Access Control Menu
This menu allows you to change the user password and enable or disable the device
security. To enter the menu, select “AccS’ from the menu list.
To select a menu option, use the Up/Down arrow keys to scroll to the desired option.
To change the password:
1. Select “PASS” in the upper window using the Up/Down arrow
keys.
2. Press SELECT to activate the first digit.
3. Set the first digit using the Up/Down arrow keys.
4. Press SELECT to advance to the next digit.
5. Set the other password digits in the same manner.
6. Press ENTER to confirm your changes and to store your new
setting, or press ESC to discard changes.
To enable or disable password protection:
1. Select “CtrL” in the upper window using the Up/Down arrow keys.
2. Press SELECT to activate the lower window.
3. Use the Up/Down arrow keys to set the desired option. Select “On”
to enable security, select “OFF’ to disable password protection.
4. Press ENTER to confirm your changes and to store your new
setting, or press ESC to discard changes.
To exit the menu:
From the upper window, press ESC.
 Note
The PM180 uses the same password for all communications ports. The password you enter is
effective for all ports, as well as in HyperTerminal, Telnet and PAS.
Reset Menu
This menu allows you to clear the energy and maximum demand accumulators,
Min/Max log, counters and device diagnostics in your PM180. To enter the Reset
menu, select rESEt from the menu list.
The following table lists available options.
Label Description
A.dnd Clears maximum ampere demands
P.dnd Clears maximum power demands
dnd Clears all maximum demands
Enrg Clears all total energies
Lo.Hi Clears Min/Max log
tOU.d Clears summary and TOU maximum demands
tOU.E Clears summary and TOU energy registers
Cnt Clears all counters
Cnt1 - Cn16 Clears counter #1 to #16
diAG Clears device diagnostics
To reset the desired value:
1. Press SELECT to activate the middle window.
2. Use the Up/Down arrow keys to scroll to the desired option.
3. Press SELECT to activate the lower window.
4. Press and hold the ENTER key for about 5 seconds until the “do”
label is replaced with “done’, and then release the key.
5. Press ESC to quit the menu.
SELECT ENERGY
ENTER
ENERGY
ENTER
CHG
 rESEt
rESEt
do
A.dnd
CtrL
OFF
PASS
0000
0000
SE
Conn=on.Erdi
P
r.
ECT
ENERGY
ENTER
ENERGY
ENTER
CHG
 AccS
