‎Appendix F Device Diagnostic Codes
182 PM180 Substation Automation Unit
Appendix F Device Diagnostic Codes
Diagnostic
Code Description Reason
0 Critical error Unrecoverable system failure - device
operation stops
1 Permanent fault (critical error) Repeated unrecoverable failure
2 Memory/Data error Hardware failure
3 Hardware watchdog reset Hardware failure
4 DSP/Sampling fault Hardware failure
5 CPU exception Hardware failure
7 Software watchdog timeout Hardware failure
8 Power down/Up Loss of power
9 Warm restart/Device reset External restart via communications or
by firmware upgrade
10 Configuration reset Corrupted setup data has been
replaced with the default configuration
11 RTC fault (critical error) The clock time has been lost
12 Configuration fault (critical error) Factory, calibration or basic device
configuration data has been corrupted
14 Expanded memory fault Hardware failure
15 CPU EEPROM fault Hardware failure
16 AC board EEPROM fault Hardware failure
17 I/O board EEPROM fault Hardware failure
20 C Library error Hardware failure
21 RTOS Kernel error Hardware failure
22 Task error Hardware failure
24 IRIG-B signal lost No IRIG-B signal from the GPS master
clock. Cleared automatically when the
IRIG-B signal is detected.
25 IRIG-B time unlocked The GPS master clock has lost the
satellite signal. Cleared automatically
when the satellite signal is locked.
NOTE
A critical error is an unrecoverable hardware or configuration failure that causes the
device to release all its outputs and to stop normal operation until the critical error is
cleared.
See
Device Diagnostics for more information on the PM180 built-in diagnostics. See
Viewing and Clearing Device Diagnostics in Chapter 11, Viewing and Clearing
Device Diagnostics in Chapter 4, and Status Information Display in Chapter 3 on how
to inspect and clear the device diagnostics.
