‎Appendix C Parameters for Monitoring and Data Logging
158 PM180 Substation Automation Unit
Designation Description
kVA L2 kVA L2
kVA L3 kVA L3
PF L1 Power factor L1
PF L2 Power factor L2
PF L3 Power factor L3
V1 THD V1/V12 Voltage THD 1
V2 THD V2/V23 Voltage THD 1
V3 THD V3/V31 Voltage THD 1
I1 THD I1 Current THD
I2 THD I2 Current THD
I3 THD I3 Current THD
I1 KF I1 K-Factor
I2 KF I2 K-Factor
I3 KF I3 K-Factor
I1 TDD I1 Current TDD
I2 TDD I2 Current TDD
I3 TDD I3 Current TDD
V12 V12 Voltage
V23 V23 Voltage
V31 V31 Voltage
I1x I1x Current
I2x I2x Current
I3x I3x Current
RT LOW 1-Cycle Low Values on any Phase
V LOW Low L-N voltage
I LOW Low current
kW LOW Low kW
kvar LOW Low kvar
kVA LOW Low kVA
PF LAG LOW Low lagging PF
PF LEAD LOW Low leading PF
THD LOW Low voltage THD 1
V THD LOW Low current THD
KF LOW Low K-Factor
I TDD LOW Low current TDD
V L-L LOW Low L-L voltage
V THD/I LOW Low voltage interharmonics THD 1
I THD/I LOW Low current interharmonics THD
RT HIGH 1-Cycle High Values on any Phase
V HIGH High L-N voltage
I HIGH High current
kW HIGH High kW
kvar HIGH High kvar
kVA HIGH High kVA
PF LAG LOW High PF Lag
PF LEAD LOW High PF Lead
THD LOW High voltage THD 1
V THD LOW High current THD
KF LOW High K-Factor
I TDD LOW High current TDD
V L-L LOW High L-L voltage
V THD/I LOW High voltage interharmonics THD 1
I THD/I LOW High current interharmonics THD
RT TOTAL 1-Cycle Total Values
kW Total kW
