‎Chapter 3 Using the RDM Status Information Display
PM180 Substation Automation Unit 31
Page Label Parameter Units LED
EP.
Mvarh export Mvarh
6 U-h
Volt-hours
7 A-h
Ampere-hours
Status Information Display
The RDM has separate status information pages accessible through the MAIN RDM
menu. For information on navigating in the RDM menus, s
ee “Using the Menus”.
To enter the Status Information Display:
1. From the Data display, press SELECT to enter the Main Menu.
The “STA” window flashes.
2. Press ENTER to enter the Status Information Display. Use the
UP/DOWN arrow keys to scroll through the status pages.
To exit the Status Information Display:
1. Press ESC to return to the Main Menu.
2. Press ESC to return to the Data display.
The Status Information Display allows you to view Device Diagnostics, status of
digital inputs and relays, counters and a phase rotation order. It is especially useful
when you connect the PM180 inputs and outputs to external equipment.
The table below lists the status information pages.
Page Parameter Description
1 diAG When a critical error occurs, the “Critic.
E
rror” message is displayed (see
Diagnostics Mode
)
Critic
Error/nonE
2 rEL.
1.2.3.4.5.6
Relay #1-6 status 0 = relay is open, 1 = relay is closed
3 St.In
1.2.3.4.5.6
Digital (status) Inputs #1-#6 0 = open, 1 = closed
4 St.In
7.8.9.A.b.C
Digital (status) Inputs #7-#12 0 = open, 1 = closed
5 Cnt.1
Counter #1
6 Cnt.2
Counter #2
…
20 Cnt.16
Counter #16
21 PHAS.
rOt.
Phase rotation order (POS/NEG/ERR)
