Chapter 7 Programming the PM180
Changing Port Settings
58
PM180 Substation Automation Unit
Chapter 7 Programming the PM180
This chapter describes how to configure the PM180 for your particular environment
and application using PAS. To access your device configuration options, you should
create a site database for your device as shown in Chapter 6.
Authorization
If the device is password protected (see
Changing the Password and Security
in Chapter 4), you are prompted for the
password when sending the new setup data to the device.
Enter the password and click OK. If your authorization was successful, you are not
prompted for the password again until you close the dialog window.
Changing Port Settings
Setting Up Communication Ports
To enter the setup dialog, select the site from the list box on the PAS toolbar, select
Communications Setup from the Meter Setup menu, and then click on the Serial
Ports Setup tab. In the Port box, select the desired device port.
To change the port settings in your device, select desired port parameters, and then
click Send. For the available communication options, see
in Chapter 3.
