‎Appendix C Parameters for Monitoring and Data Logging
PM180 Substation Automation Unit 165
Designation Description
I4 TDD I4 TDD
I1 KF I1 K-Factor
I2 KF I2 K-Factor
I3 KF I3 K-Factor
I4 KF I4 K-Factor
V1 CF V1/V12 Crest Factor 1
V2 CF V2/V23 Crest Factor 1
V3 CF V3/V31 Crest Factor 1
V4 CF V4 Crest Factor
I1 CF I1 Crest Factor
I2 CF I2 Crest Factor
I3 CF I3 Crest Factor
I4 CF I4 Crest Factor
PHASORS Phasors
V1 Mag V1/V12 Voltage magnitude 1
V2 Mag V2/V23 Voltage magnitude 1
V3 Mag V3/V31 Voltage magnitude 1
V4 Mag V4 Voltage magnitude
I1 Mag I1 Current magnitude
I2 Mag I2 Current magnitude
I3 Mag I3 Current magnitude
I4 Mag I4 Current magnitude
V1 Ang V1/V12 Voltage angle 1
V2 Ang V2/V23 Voltage angle 1
V3 Ang V3/V31 Voltage angle 1
V4 Ang V4 Voltage angle
I1 Ang I1 Current angle
I2 Ang I2 Current angle
I3 Ang I3 Current angle
I4 Ang I4 Current angle
I1x Mag I1x Current magnitude
I2x Mag I2x Current magnitude
I3x Mag I3x Current magnitude
I4x Mag I4x Current magnitude
I1x Ang I1x Current angle
I2x Ang I2x Current angle
I3x Ang I3x Current angle
I4x Ang I4x Current angle
DEMANDS Present Demands
V1 DMD V1/V12 Volt demand 1
V2 DMD V2/V23 Volt demand 1
V3 DMD V3/V31 Volt demand 1
I1 DMD I1 Ampere demand
I2 DMD I2 Ampere demand
I3 DMD I3 Ampere demand
kW IMP BD kW import block demand
kvar IMP BD kvar import block demand
kVA BD kVA block demand
kW IMP SD kW import sliding window demand
kvar IMP SD kvar import sliding window demand
kVA SD kVA sliding window demand
kW IMP ACC DMD kW import accumulated demand
kvar IMP ACC DMD kvar import accumulated demand
