Chapter 3 Using the RDM Using the Menus
SA300 Substation Automation Unit 33
Page Parameter Description
Cnt.1 5
Counter #1
Cnt.2 6
Counter #2
…
Cnt.16 20
Counter #16
PHAS.
rOt.
21
Phase rotation order (POS/NEG/ERR)
Resetting Counters
When changing data is not password protected, you can reset the counters from the
Status Information Menu display without entering the reset menu:
1. Select a display page where the counter you want to reset is
displayed.
2. While holding the SELECT key, press and hold the ENTER key for
about 5 seconds until the displayed data is reset to zero.
Resetting Device Diagnostics
When the Device Diagnostics page shows a critical error, you can clear it from this
page:
1. Select the Device Diagnostics page.
2. While holding the SELECT key, press and hold the ENTER key for
about 5 seconds until the displayed data is reset to NONE.
Using the Menus
The RDM menus allow you to configure your RDM display and set up primary
parameters in the SA300, such as time, basic device configuration, serial ports
settings, security settings (passwords and protection status). Through the RDM
menus, you can also easily reset main accumulated values, such as device counters,
energy registers, maximum demands, Min/Max log, and device diagnostics.
Navigation Keys
In the RDM menus, the navigation keys are used as follows:
SELECT
SELECT - Selects an active window (selected window is flashing)
ENTER
ENTER - Enters menu/sub-menu or confirms changes made in the active window
ESC
ESC - Returns to a higher menu or aborts changes made in the active window
UP ARROW
UP ARROW - Scrolls options forwards or increments a number in the active window
ENERGY
ENTER
THD/TDD
ESC
S
T
SELECT
